Key specifications and features:
Rational structure and modern design
Scientific design of heat dissipation and optics
High level aluminum edge, which is better for the heat dissipation of LED itself and keeps a longer lifespan
Wide output voltage
No harsh glare, activated without delay and high-powered factor
Luminous depreciation: <5%
Eyesight protection
Used for long working time and study circumstances
Lighting effect of the whole panel light 80lm/W and advanced lighting features
Compared with traditional fluorescent lamp, this LED panel saves over three times electricity in the same luminance
intensity
Self-design and strictly testing LED driver, we assure the high quality and good after-sales service
85% light transmission of LGP (light guide plate)
More even light and higher luminous
LED type of 600 x 600mm and LED panel light: 3528, 3535 and 5630SMD LED
Thickness of LED panel light: 12mm
LED panel light dimensions: 600 x 600 x 12mm
LED panel light guide main material cover: acrylic light guide board (guide light from four edges)
Colors: single, bi-color and RGB
Various colors are available
Input voltages: 85 to 265V AC
Power: 40W (3528SMD) and 60W (3535 and 5630SMD)
LED quantity: 396 or 220 pieces
Luminous efficiency: 87 to 104lm/W
Luminous flux of pure white: 4,161/3528SMD, 5,275/3535SMD and 5,866lm/5630SMD
Ambient temperatures: -30 to 70掳C
Lifespan: 鈮100,000 hours
Beam angle: 120掳
Installation of LED panel: convenient and efficient, both centenary and push in type are available
Other dimensions:
12 x 300 x 300mm
12 x 300 x 600mm
12 x 595 x 595mm
12 x 600 x 600mm
12 x 300 x 1,200mm
12 x 600 x 1,200mm
With CE, RoHS, FCC and ETL marks
|
